Provides frequency from 4GHz up to 6GHz In and Out on the rear panel Specify Non-harmonics for frequency 136 MHz to 174 MHz to be less than -75 dBc Provide ACLR less than= - 60dbc for muti-carrier WCDMA Tested 100 Hz phase noise at 6 GHz and 100 Hz spurs at 5.18 GHz Provide ACLR <= 58db for multi-carrier WCDMA Increases the I/Q output voltage from 1.5V pk-pk to 3.0V pk-pk for the E4438C 420 to operate in the E4438CĮxtends the lower limit to Swept-Sine frequency to 25 MHz for LF Out Signal studio for pulse building for the E8267C opt. Warranted +16dBm maximum leveled RF output over 250MHz to 3GHz with option 506 Improved Phase Noise performance for a specific frequency Signal Studio for WiMAX for Wireless MAN-OFDM physical layer Hardware option for E4438C (506/UNM/UNB/UNJ/1E5) Hardware option for E4438C 504,UNM,UNB,UNJ,1E5
Hardware option for E4438C 504,UNM,UNB,UNP,1E5 Hardware option for E4438C 504,UNM,UNN,UNJ,1E5 Hardware option for E4438C 504,UNM,UNN,UNP,1E5 Hardware option for E4438C 503,1EM,UNB,UNJ,1E5 Hardware option for E4438C 503,1EM,UNB,UNP,1E5 Japan Quick Users Guide (Japanese localization) Quick Users Guide (English localization)įrance Quick Users Guide (French localization) Korea Quick Users Guide (Korean localization)Ĭhina Quick Users Guide (Chinese localization) Taiwan Quick Users Guide (Chinese localization)
#E4438c series#
Internal baseband generator, 64 Msa memory with digital bus capabilityĮSG-C Series ANSI Z540 compliant calibration with test data Internal baseband generator, 8 Msa memory with digital bus capability Signal Studio for noise power ratio (NPR) Signal Studio for 802.11 WLAN consists of Opt 405/410/415 Signal Studio for Enhanced Multi-tone signals TDMA personalities (GSM, EDGE, NADC, PDC, PHS, DECT, TETRA) GSM/EDGE basestation loop back BER test capability Moves all front panel connectors to rear panel
#E4438c generator#
Internal Base Band Generator w/ 32 MRAM updated to 602Įnables ESG digital output connectivity with N5102AĮnables ESG digital input connectivity with N5102AĮSG-C Series ISO 17025 compliant calibration with test data Internal Base Band Generator w/1 MRAM updated to 601 Multi-channel baseband generation with N5102A Digital I/O, MIMO fading and RF to RF fading with PXB Baseband Generator and Channel Emulatorīackwards compatible with ESG, PSG and 8648 signal generators <-134 dBc phase noise at 1 GHz and 20 kHz offset typicalĨ0 MHz dual mode internal baseband generator: arbitrary waveform and real-time I/QĬreate reference signals: LTE, HSPA+, WiMAX™, WLAN, DVB-H, GPS, MATLAB and more - Signal Studio
#E4438c upgrade#
Its modular architecture makes it easy to configure the instrument with the level of performance and signal creation capability you need today with the option to upgrade in the future. The E4438C ESG is an adaptable platform with optional capabilities to customize the instrument for baseband and RF test applications ranging from simple distortion test and general purpose troubleshooting to baseband coding algorithm development, advanced transceiver design verification, and high volume manufacturing. Modular Architecture to Meet your Test Requirements
Offering an internal baseband generator with arbitrary waveform and real-time I/Q capabilities, ample waveform playback and storage memory, and a wide RF modulation bandwidth, the E4438C ESG is equipped to test today''s complex wireless systems and their components. RF Performance and Leading-Edge Baseband GenerationĪgilent''s E4438C ESG vector signal generator combines outstanding RF performance and sophisticated baseband generation to deliver calibrated test signals at baseband, IF, and RF frequencies up to 6 GHz.
